Long
Range Wireless Communication Platform
|
 |
ib-241000
2.4GHz Long Range Wireless LAN Platform for
Data & Voice Transmission
Digital long-range wireless transmission for data and
voice.Extending LAN, VOIP, phone, Internet…data,
image, voice over 10Km~25Km.True Outdoor Unit (Weather-proof,
-35c ~ 70c ).3 operating mode: Bridge, AP, WEC (CPE)
Extending multi-phone lines, LAN network from urban
through
far isolated rural areas: islands, mountains, villages,
stand-alone farms, isolated construction sites, mines,
jungles. Expanding and bridging multi-phone lines, existing
LAN network among buildings, offices, companies, branches,
cities, groups, factories.Combining usage of WEB related
equipments like VOIP, camera… for versatile applications.
Advantages especially great in those areas lacking of
well broad-band infrastructure.
Learn more
| Download
PDF |
| |
| |
| Long
Range Wireless Communication Platform |
 |
ib24200
2.4GHz Long Range Wireless LAN Platform for Data
& Voice Transmission
Digital long-range wireless transmission for data and
voice.Extending LAN, VOIP, phone, Internet…data,
image, voice over 10Km~25Km.True Outdoor Unit (Weather-proof,
-35c ~ 70c ).3 operating mode: Bridge, AP, WEC (CPE)
Extending multi-phone lines, LAN network from urban
through
far isolated rural areas: islands, mountains, villages,
stand-alone farms, isolated construction sites, mines,
jungles. Expanding and bridging multi-phone lines, existing
LAN network among buildings, offices, companies, branches,
cities, groups, factories.Combining usage of WEB related
equipments like VOIP, camera… for versatile applications.
Advantages especially great in those areas lacking of
well broad-band infrastructure.
Learn more
| Download
PDF |
| |
| |
| Antenna's |
| Wireless Omni Antenna |
 |
ib-OD-9/12
Vertically Polarized Omni Directional Antenna’s
2400 to 2485 MHz Operation
The Omni Directional antenna systems offered by ibridge
Networks Inc. are constructed of UV-stable fiberglass
with all stainless steel brackets standard. They come
standard with Type N female bulkhead connectors with
extra heavy duty nuts for optional standoff type mounting.
The 12dBi has a 3 Deg Electrical Downtilt standard.
It also has 24” pigtail option with N Female or
N Male connectors for direct connection to outdoor access
points. The 9dBi is available with 0 degree electrical
downtilt and 7 degree electrical downtilt which is perfect
for close-in wireless systems such as apartment complexes.
Because of their unique high performance design which
eliminates nulls, they can be used in a wide variety
of wireless systems.
Learn more
| Download
PDF |
| |
| |
| Wireless Panel Antenna
- ib24-14 |
|
ib24-14
ibridge Panel Antenna 2400 to 2485 MHz Operation
The ib 24-14 panel antenna offered by ibridge Network
Inc. is developed to allow integration of the customers’
radio equipment inside the weatherproof compartment.
The radio compartment is big enough to house transceivers,
amplifiers, and other electronic equipment. Two sizes
are available, our regular and a new Lower Profile.
The antenna design utilizes a suspended wire element
over a solid 8.5” square backplane for more consistent
performance over temperature and humidity conditions.
The housing is UV stabilized ABS plastic. The backplate
is alodine coated aluminum with stainless steel fasteners.
All bracket fasteners are stainless steel for corrosion
protection.
Learn more
| Download
PDF |
| |
| |
| Wireless Panel Antenna
- ib24-18 |
|
ib24-18
ibridge Panel Antenna 2400 to 2485 MHz Operation
The ib24-18 panel antenna offered by ibridge Networks
Inc. is designed to allow integration of the customers’
radio equipment inside the weatherproof compartment.
The radio compartment is big enough to house transceivers,
amplifiers, and other electronic equipment. The antenna
design utilizes a unique suspended wire element over
a solid backplane for more consistent performance over
temperature and humidity conditions. The unit includes
a unique “breadboard” layer inside the back
cover to allow the customer to mount any various electronics
using 8-32 screws. The housing is UV stabilized ABS
plastic. The backplate is alodine coated aluminum with
stainless steel fasteners. All bracket fasteners are
stainless steel for corrosion protection.
Learn more
| Download
PDF |
| |
| |
| ibridge Echo Series
Antenna |
|
ibES24-14
ibridge Echo Series Antenna 2400 to 2438 MHz Operations
The Echo Series antenna system offered
by ibridge Networks Inc. is constructed of aluminum
alloy with powder-coat painted finish. They come standard
with an integral N Female
connector and heavy duty U-bolt bracket. A cone mount
bracket is also available for surface installations.
The Echo Series antenna can be used in a wide variety
of wireless systems. Its superior front to back performance
minimizes external interference coming from behind the
unit which makes it desirable for high-density antenna
installations or installations where the installer wants
to minimize interference.
Learn more
|Download
PDF |
| |
| |
| ibridge Mini Directional
Antenna |
|
ibMDA-12
The 2.4GHz Mini Directional antennas offered by ibridge
Networks Inc. are a sub-compact antenna for the most
demanding client applications. The antennas offer high
gain in an ultrasmall aesthetically pleasing package.
The antennas are constructed of gray color UV ABS plastic
with aluminum backplate and stainless steel mounting
bracket. The antenna can be used in Horizontal or Vertical
Polarization by making a change to bracket mounting.
The stainless steel bracket affords +/- 15 deg tilt
adjustment. The compact low visual impact attractive
styling blends well in almost any application. The antenna
comes with an integral N Female connector standard.
Learn more
| Download
PDF |
| |
| |
| ibridge Vertically Polarized
Sector Antennas |
|
ibSA-17
ibridge Vertically Polarized Sector Antenna
2400 to 2485 MHz Operation
The Vertically Polarized Sector antenna systems offered
by ibridge Networks Inc.are constructed of UV stable
fiberglass radomes for extremely long service life in
the most demanding conditions. The antennas are constructed
using corrosion resistant metal elements which are more
stable than PCB based antenna systems because they don’t
absorb moisture, which can degrade the performance of
PCB based antenna systems. The 17dB sector comes with
a stainless steel scissor bracket system for ease of
installation and aligning. The 9dBi sector comes with
a galvanized steel bracket with stainless steel hardware.
Learn more
|Download
PDF |
| |
| |
| ibridge Sector Antenna
Systems |
|
ibSHA24-12-16
ibridge Sector Antenna 2400 to 2483 MHz Operation
The Sector antenna systems offered
by ibridge networks Inc. are constructed from rigid
aluminum extrusion, these units are powder coated and
sealed with PTFE (Teflon) tape providing lightweight,
rigid, weatherproof units. They feature 50 ohm passive
feeds that come standard with type N female connectors.
Pacific Wireless offers two different bracket systems
with these antennas: A) The super heavy duty single
point galvanized bracket system is designed for ease
of installation and pole-top mounting B) The all stainless
steel 2 point scissor bracket gives increased stability
and improved downtilt adjustment accuracy. Both brackets
offer 10deg of mechanical downtilt. The N connector
is positioned on the front/transmission side of the
sector.
Learn more
| Download
PDF |
| |
| |
| ibridge Vagi Series
Antenna |
|
ibVA24-16
ibridge Vagi Series Antenna 2400 to 2485
MHz Operation The Vagi Series
antenna system offered by ibridge Networks Inc. is constructed
of Die Cast Aluminum Alloy with anticorrosion alodine
finish. They come standard with a choice of an N Female
or N Male connector and an adjustable 45 Deg Tilt galvanized
steel QuikClamp bracket which accommodates a 1”
to 1.5” pole diameter. The Vagi Series antenna
can be used in a wide variety of wireless systems where
low cost, good performance and low wind loading are
important factors. Because of their low visual impact,
they have been approved for use by many homeowner associations
with strict CC&R restrictions. Various frequency
options are available between 1700 and 2700 MHz.
Learn more
| Download
PDF |
|
| |
| |
| Accessories |
| Universal
Wall Mount Bracket |
 |
ib_um
The Universal Wall Mounting Brackets are constructed of zinc
plated steel for long service life.The mount seams are welded
for durability. The mount provides 8” of standoff from
the wall and supports over 35LBs. The mount is attached to
the wall with two screws and can be mounted very quickly.
The industry standard 1.25” mount diameter allows mounting
of most pole type mount antennas. Typically the pole mount
type antenna has a bracket, which accommodates full tilt and
azimuth adjustment.
Learn more
| Download
PDF |
| |
| |
| Universal
Wall Mount Bracket |

|
um_uml
The ibridge Universal Antenna Mounting Systems consist of
a universal bracket and choice of 2 different length mounting
tube for the most demanding customer premises antenna mounting
applications. The construction is better than many of these
types of mounts, which are only light gauge painted steel.
The ibridge Networks mounts are heavy gauge (military grade)
steel which goes thru a galvanization (plating) process and
then are powder coat painted for extra protection from the
elements. Fasteners used are stainless steel. The mounting
tubes have 2 sets of holes to give maximum angular flexibility
during installations. The mounting systems feature a universal
mounting bracket with a full 90 degrees of tilt whichallows
for greater versatility when dealing with the variety of installation
challenges found at customer sites. Their low profile and
attractive styling make it ideal for installations on various
styles of buildings and in all neighborhoods, including upscale
neighborhoods.
Learn more
| Download
